Stand-Alone Chlorine Gas Monitor

SKU: A14C

$1,865.00

  • 0-10 PPM Chlorine Gas Sensor
  • 2 Module Enclosure – houses one receiver and one power supply
  • Power Supply Module
  • LED Display
  • Analog Output
  • Two Alarm Setpoints
  • Three Alarm Relays
  • Trouble Alarm and Relay
  • Front Panel Reset Switch
  • Remote Reset Input
  • Pluggable Terminal Blocks
SKU: A14C Categories: Gas Monitors, Lift Station Gas Monitors, Water - Booster Pump Station, Water - Elevated Tank, Water - Ground Storage Tank
  • Description
  • Additional information
  • Applications
  • Brochures

Description

GasSens is a flexible component system providing a variety of options to meet individual gas detection and alarm requirements. From chemical and petrochemical plants to food processors, the GasSens system can be applied to the simplest or most complex gas detection application. Economical and low maintenance, this system is your best choice for reliable leak detection. GasSens detection systems consist of individual modules that can be located where required. Sensor/transmitters, located in the area where gas leakage or buildup might occur, provide the basic measurement for the system. Sensor transmitters are available in either NEMA 4X or explosion-proof versions and can be supplied with ATI’s exclusive Auto-Test automatic sensor testing system, greatly reducing operator testing requirements. Receiver modules provide the electronic brains for the detection and alarm system. Each compact module includes a digital display of gas concentration, isolated analog output, and 4 relay outputs. Receivers may be located up to 1000 feet from sensor/transmitters for remote indication, or can provide local control functions such as valve shutoff while transmitting a 4-20 mA signal to remote displays or data loggers. Universal power supply modules provide DC power to receivers. The power supply is housed in a compact module similar to the receiver, and will accept inputs from 85 to 265 volts, AC or DC, without adjustment. The power supply also provides a power failure relay and charging for an optional battery back-up unit.

Additional information

Weight 10 lbs
Dimensions 12 × 12 × 12 in
Model

A14C

Feature

0-10 PPM Chlorine Gas Sensor 2 Module Enclosure – houses one receiver and one power supplyPower Supply ModuleLED DisplayAnalog OutputTwo Alarm SetpointsThree Alarm RelaysTrouble Alarm and RelayFront

Suitable Replacement

This product is a suitable replacement for the following: ATI A14/A11 GasSens Modular Gas Detector  Others

Water - Booster Pump Station

Water - Booster Pump Station

Water - Elevated Tank

Water - Elevated Tank

Water - Ground Storage Tank

Water - Ground Storage Tank

Stand-Alone Gas Monitor Brochure

Stand-Alone Gas Monitor Brochure
