5000 Series Chart Recorder

SKU: MRC5000

From: $1,666.08

Product Quantity

Red Pens (5-pack)

0 to 10, 24-hour Circular Chart

0 to 10, 7-day Circular Chart

0 to 100, 31-day Circular Chart

    • Record only or high/low limit and record/control functionality
    • 4 digit, 0.56” high, red, seven segment LED display with keypad
    • 10” circular charts
    • 8hr, 12hr, 24hr, 48hr, or 7 day chart rotation
    • -9999 to 9999 unit chart span
    • Up to 2 disposable fiber tip pens
    • Non-volatile EEPROM for configuration parameters, calibration, and alarm setpoint data
    • Injection molded Noryl case with acrylic window cover
    • 90-246VAC line voltage at 50-60Hz
    SKU: MRC5000 Categories: Booster Pump Station Recorder, Chart Recorders, Elevated Tank Recorders, Ground Storage Tank Recorders, Hydropneumatic Station Monitor Recorders, Lift Station Recorders, Wastewater - Lift Station, Water - Booster Pump Station, Water - Elevated Tank, Water - Ground Storage Tank, Water - Hydropneumatic Station, Water - Well, Water Well Recorders
    • Description
    • Additional information
    • Applications
    • Brochures

    Description

    The 5000 Series Chart Recorder is a digital circle chart recorder capable of measuring, recording and controlling up to two process variables from a variety of inputs. The MRC 5000 directly connects to either thermocouple, RTD, mVDC, VDC, or mADC inputs. Changes in input type are easily accomplished in the field through programming. This instrument has a universal power supply, 90–264VAC line voltage at 50–60Hz.





    If a desired option or accessory is not shown, please submit an inquiry.

    Additional information

    Weight 16 lbs
    Dimensions 8 × 18 × 18 in
    Model

    MRC50002

    Feature

    Record only or high/low limit and record/control functionality 4 digit, 0.56'' high, red, seven segment LED display with keypad 10'' circular charts 8hr, 12hr, 24hr, 48hr, or 7 day chart rotatio

    Suitable Replacement

    This product is a suitable replacement for the following: Eurotherm Model 392 Partlow Model MRC5000

    Red Pens (5-pack)

    Model

    PartlowRedPen5

    0 to 10, 24-hour Circular Chart

    Model

    Partlow 0to10-24hour

    0 to 10, 7-day Circular Chart

    Model

    Partlow 0to10-7day

    0 to 100, 31-day Circular Chart

    Model

    Partlow 0to100-31day

    Wastewater - Lift Station

    Wastewater - Lift Station

    Water - Booster Pump Station

    Water - Booster Pump Station

    Water - Elevated Tank

    Water - Elevated Tank

    Water - Ground Storage Tank

    Water - Ground Storage Tank

    Water - Hydropneumatic Station

    Water - Hydropneumatic Station

    Water - Well

    Water - Well

    5000 Series Chart Recorder Brochure

    5000 Series Chart Recorder Brochure
